Overview
The Ford Powerstroke 6.7L Cold Side Intercooler Pipe (2017-2024) by S&B replaces the factory cold-side intercooler pipe on compatible Ford Super Duty trucks equipped with the 6.7L Powerstroke diesel engine. It features a 3.50-inch polished aluminum charge-air cooler (CAC) pipe, a 5-ply aramid-reinforced silicone hose, and heavy-duty T-bolt clamps designed to support airflow and withstand boost pressure.
Vehicle Fitment
- Model Years: 2017-2026, according to the supplied compatibility information
- Make: Ford
- Models: F-250, F-350, F-450 (2017-2022 and 2023-2026), F-550 (2017-2022)
- Engine: 6.7L Powerstroke Diesel, including High Output variants
- Body Style: Pickup
Key Features
- 3.50-Inch Polished Aluminum Pipe: Larger-diameter CAC piping designed to reduce restriction and support airflow.
- 5-Ply Aramid-Reinforced Silicone Hose: Designed to withstand sustained boost pressure.
- Heavy-Duty T-Bolt Clamps: Spring-loaded clamps with 3/4-inch stainless steel bands and bridges for secure connections.
- Two-Piece Design: Designed to simplify installation without cutting or fabrication.
- OEM Replacement Compatibility: Replaces factory part numbers HC3Z-6F073-A, HC3Z-6F073-B, and PC3Z-6F073-B.
Technical Specifications
| Specification | Detail |
|---|---|
| Pipe Diameter | 3.50 inches |
| Pipe Material | Polished aluminum |
| Hose Construction | 5-ply aramid-reinforced silicone |
| Clamp Type | Spring-loaded T-bolt with 3/4-inch stainless steel band |
| Design | Two-piece |
| OEM Replacement Part Numbers | HC3Z-6F073-A, HC3Z-6F073-B, PC3Z-6F073-B |
| CARB Exemption | F-250, F-350, and F-450: EO D-590-42, D-590-49, D-590-56. No CARB EO for F-550. |
| Street Legality | Listed as 50-state compliant for F-250, F-350, and F-450 |
Benefits
- Reinforced Charge-Air Connection: The upgraded hose and clamps are designed to address factory pipe and hose failure under boost.
- Airflow Support: The larger-diameter pipe is designed to reduce restriction in the cold-side charge-air path.
- Boost Leak Prevention: Heavy-duty T-bolt clamps help secure the pipe and hose connections.
- Installation Convenience: The two-piece design is intended to simplify installation without cutting or fabrication.
Installation Notes
- The two-piece design is intended for straightforward installation without cutting or fabrication.
- Inspect the intercooler outlet and intake manifold inlet boots before installation.
- Perform a boost leak check before returning the vehicle to service.
- A step-by-step installation video is available from S&B.
- This item ships directly from the manufacturer. Allow 1-2 weeks for delivery.
Frequently Asked Questions
Does this fit the High Output 6.7L Powerstroke?
Yes. The supplied product information lists compatibility with 6.7L Powerstroke trucks, including High Output variants. Verify the exact model year and vehicle configuration before ordering.
Does this fit the F-450 and F-550?
The listed fitment includes F-450 models from 2017-2022 and 2023-2026, and F-550 models from 2017-2022. For 2023 and newer F-550 Cab & Chassis trucks, the supplied information references S&B part 83-1012.
Is this street legal in California?
The supplied information lists F-250, F-350, and F-450 applications as 50-state compliant and states that the F-550 does not have a CARB Executive Order exemption. Confirm current compliance for your exact application before purchasing.
What OEM part numbers does this replace?
This pipe replaces OEM part numbers HC3Z-6F073-A, HC3Z-6F073-B, and PC3Z-6F073-B.
How long does shipping take?
This item ships directly from the manufacturer. Allow 1-2 weeks for delivery.
Note:
- Verify model-year, engine, and body-style compatibility before ordering.
- For 2023 and newer F-550 Cab & Chassis applications, refer to S&B part 83-1012 as specified in the supplied product information.
- F-550 applications do not have the CARB EO exemption listed for F-250, F-350, and F-450.
- Ships directly from the manufacturer. Allow 1-2 weeks for delivery.
